Pressure Tranducer

    Tag: .

    Deskripsi produk:

    Specifications

    Type Absolute Pressure Transducer
    Range 0 bar to 4 bar (59 psia) Absolute
    Sensitivity 1V to 5V
    Non-linearity & hysteresis ±0.2% combined
    Temp. compensated range 110°C – 140°C
    Accuracy 10mbar (0.147 psi) at 110°C – 140°C
    Calibration Pressure calibration performed at 23°C and 121°C

    Software Support

    The Kaye Validator Report Wizard provides EN554,HTM2010 and IS-17665 complaint reports. The user can create:

    • Saturated Pressure and Temperature Graph Reports utilizing temperature and pressure actual data along side calculate saturated readings
    • Automatic equilibration pass/fail determination
    • Automatic Tb, Tb+3 limit determination based on temperature versus saturate temperature, or pressure versus saturated pressure.
